XP95 High Temp Heat Detector

$1.00

Apollo 55000-401APO XP95 High Temp 90°C Heat Detector. The XP95 Heat Detector monitors temperature by using a single thermistor which provides a count output proportional to the external air temperature.

Category:

Description

Apollo 55000-401APO XP95 High Temp 90°C Heat Detector.

The XP95 Heat Detector monitors temperature by using a single thermistor which provides a count output proportional to the external air temperature.

This high temperature detector, classified as a CS devicem will report an alarm at 90°C.

Features

  • Ideal in environments that are dirty or smoky under natural conditions
  • Can be installed in a typical ambient temperature of 55°C
  • Well suited for warehouses, loading bays and carparks
  • Unaffected by wind or atmospheric pressure

Technical Data:

Manufacturer Code: 55000-401APO
Dimensions (H x W x D): D100mm x H42mm
Weight:  105g
Approval: EN54-5, SBSC, BOSEC, CPR, KRS, LPCB
Material: Polycarbonate
Sensor Type: Chevron CS
Supply Voltage: 17 to 28V DC
Operating Temperature: -20 to 70°C
IP Rating:  IP54
