Fellow Kogyo FOCAS-1800 – Surplus Unit

Measuring Method

The FOCAS-1800 using a full optical continuous measuring method* can sure grasp changes of oil concentration every moment while providing a very quick measurement response.

The light coming form optical elements is received by multiple optical elements. Then, a complicated analysis about changes of oil type or concentration add differences of pattern due to mixed foreign substances can be made by CPU and software in an instant through calculation.

Features

• This product adopts an automatic operation method using sample water pressure which is matched to the operation of an oil separator or pump.
• The automatic washing function of the detection unit can reduce troublesome manual washing work, (Optional)
• An error code indication provided at occurrence of a device fault and a stain indication of the detection unit facilitates maintenance and inspection. The product has a high-maintainability structure.
• The device can be calibrated on a ship or on the side by using a calibration unit. (However, the qualification for calibration specified by the manufacturer is required).
• Operation records such as trouble alarms can be saved in a memory card and confirmed as required.
• The product can measure only the oil concentration and is not affected by SS content (floating turbidity substance other than oil content) and surface active agent.
• For alarms, a double safety method is used. When the oil concentration is 15 ppm or more, an oil alarm is output. When sample water is defective or the instrument is defective, a trouble alarm is output.
